High - Durability Resilient Anti - Abrasion Car Window Lift Rubber Strips for Long - Lasting Use
Item specifics
- Color (General)
- Custom
- Material
- EPDM or other rubber materials: NBR, CR, IIR
- Length
- Custom
- Dimension
- Custom
- Temperature Range
- －45°C—125°C
- Shore Hardness
- 50-95 Shore A or customize
- Tensile strength
- 5～12Mpa
- Elongation at break
- 400%
Review
Description
Car Window Lift Rubber Strip Introduction
Our Car Window Lift Rubber Strip is an ideal choice for both car manufacturers and aftermarket replacements. Its easy - to - install design allows for quick and hassle - free replacement, saving time and effort.
Customization Options
RESRUB could produce the tubing with enough length to fully connect any size loop.
And available to custom colors, such as black, white, pink, etc.
Material Advantages
Crafted from premium - grade rubber, often EPDM, it offers a blend of flexibility and toughness. This material ensures the strip can endure the constant stress from window opening and closing motions without cracking or deforming.
Car Window Lift Rubber Strip Properties:
| Length | Customizable | OEM/ODM | Available |
| Logo | Customer Logo Available | Lead Time | 10 Days |
| MOQ | 100 Meters | Application | Gaming Case |
Technical Specification
EPDM rubber (ethylene propylene diene monomer rubber) is a type of synthetic rubber that is used in many applications, with outstanding resistance to oxygen, ozone, and sunlight. Additionally, it also has low temperature flexibility, excellent heat, water and steam resistance. Useful working temperature range is -60°C up to +150°C.
What is the function of the car window lift rubber strip?
The car window lift rubber strip mainly serves two key functions. Firstly, it provides a weather - tight seal. It prevents rain, dust, and wind from entering the vehicle's interior, keeping the cabin clean and dry. Secondly, it acts as a buffer between the moving window glass and the window frame. This helps to reduce noise during the window - lifting operation and protects the window glass and frame from scratches and abrasions.
How can I tell if my car window lift rubber strip needs replacement?
There are several tell - tale signs. If you notice water leaking into the car when it rains, especially around the window edges, it's a strong indication that the rubber strip has deteriorated.
What materials are used for car window lift rubber strips?
Typically, materials such as EPDM (Ethylene - Propylene - Diene Monomer), PVC (Polyvinyl Chloride), and silicone are used. EPDM is highly resistant to weathering, ozone, and aging, making it a popular choice for long - lasting performance. PVC is cost - effective and offers good flexibility. Silicone rubber is known for its excellent heat resistance and ability to maintain its shape and flexibility over a wide temperature range. The choice of material often depends on the vehicle manufacturer's requirements and the intended application.
Item | Car Window Lift Rubber Strip | |
Size | Customize | |
Material | EP90-002(0.5)+EP85-003B(0.5) | |
Hardness | 50-95 Shore A or customize | |
Color | White or customize any color | |
Density | 0.6-1.45/cm³ | |
Temperature resistant | －45°C—125°C | |
Tensile strength | 5～12Mpa | |
Elongation at break | 200～900% | |
Lead time | 3 days for sample, 15 days for batch order | |
Packing method | Carton/ PE bag / Wooden pallet / Paper roll | |
Price tip | The price above is for your reference, final actual price depends on your design,material request, surface treatment, order quantity, package request, etc. | |
